Kissimmee Gateway Airport (ISM) Information
Orlando, FL
|
Latest photos of Kissimmee Gateway Airport (ISM)
by Kreg Anderson |
by Daniel Compton |
by Daniel Compton |
by Daniel Compton |
Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | ISM |
| Airport Status: | Operational |
| Longitude/Latitude: | 081-26-13.5000W/28-17-23.3000N
-81.437083/28.289806 (Estimated) |
| Elevation: | 82 ft / 24.99 m (Surveyed) |
| Land: | 892 acres |
| From nearest city: | 16 nautical miles SW of Orlando, FL |
| Location: | Osceola County, FL |
| Magnetic Variation: | 05W (2000) |
Owner & Manager
| Ownership: | Publicly owned |
| Owner: | City Of Kissimmee |
| Address: | 301 Dyer Blvd Suite 101
Kissimmee, FL 34741-4613 |
| Phone number: | 407-847-4600 |
| Manager: | Terry Lloyd |
| Address: | 301 Dyer Blvd Suite 101
Kissimmee, FL 34741-4613 |
| Phone number: | 407-847-4600
FAX 407-847-8399 AMGR. |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | Yes |
| Control Tower: | Yes |
| Lighting Schedule: | DUSK-DAWN
MIRL RY 15/33 & RY 06/24 PRESET LOW INTST DUSK-2200; TO INCR INTST & ACTVT AFTER 2200 - CTAF. ACTVT MALSF RY 15, PAPI RYS 06, 24, 15 & 33 - CTAF. |
| Beacon Color: | Clear-Green (lighted land airport) |
| Landing fee charge: | No |
| Sectional chart: | Jacksonville |
| Region: | ASO - Southern |
| Boundary ARTCC: | ZMA - Miami |
| Responsible ARTCC: | ZJX - Jacksonville |
| Tie-in FSS: | PIE - Saint Petersburg |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | ISM (NOTAM-d service avaliable) |
| Federal Agreements: | NGPRY3 |
Airport Communications
| CTAF: | 124.450 |
| Unicom: | 122.950 |
Airport Services
| Fuel available: | 100LLA |
| Airframe Repair: | MAJOR |
| Power Plant Repair: | MAJOR |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | HIGH |
|
Runway Information
Runway 06/24
| Dimension: | 5000 x 150 ft / 1524.0 x 45.7 m |
| Surface: | ASPH, Good Condition |
| Surface Treatment: | Saw-cut or plastic Grooved |
| Weight Limit: | Single wheel: 30000 lbs.
Dual wheel: 60000 lbs. |
| Edge Lights: | Medium |
| |
Runway 06 |
Runway 24 |
| Longitude: | 081-26-38.5767W | 081-25-51.1108W |
| Latitude: | 28-17-12.6405N | 28-17-38.8316N |
| Elevation: | 80.00 ft | 78.00 ft |
| Alignment: | 58 | 127 |
| Traffic Pattern: | Right | Left |
| Markings: | Non-precision instrument, Fair Condition | Non-precision instrument, Good Condition |
| Crossing Height: | 45.00 ft | 45.00 ft |
| VASI: | 4-light PAPI on left side | 4-light PAPI on left side |
| Visual Glide Angle: | 3.00° | 3.00° |
|
Runway 15/33
| Dimension: | 6000 x 100 ft / 1828.8 x 30.5 m |
| Surface: | ASPH, Good Condition |
| Surface Treatment: | Saw-cut or plastic Grooved |
| Weight Limit: | Single wheel: 75000 lbs.
Dual wheel: 75000 lbs.
Dual tandem wheel: 120000 lbs. |
| Edge Lights: | Medium |
| |
Runway 15 |
Runway 33 |
| Longitude: | 081-26-30.1108W | 081-25-54.6251W |
| Latitude: | 28-17-46.4898N | 28-16-56.0650N |
| Elevation: | 80.00 ft | 77.00 ft |
| Alignment: | 127 | 127 |
| ILS Type: | ILS/DME
| |
| Traffic Pattern: | Right | Left |
| Markings: | Precision instrument, Good Condition | Non-precision instrument, Good Condition |
| Crossing Height: | 51.00 ft | 45.00 ft |
| VASI: | 4-light PAPI on left side | 4-light PAPI on left side |
| Visual Glide Angle: | 3.00° | 3.00° |
| Approach lights: | MALSF | |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| ISM | NDB | Kissimmee | | 329.00 | 05W | 0.2 nm |
| SFB | NDB | Sanford | | 408.00 | 05W | 31.5 nm |
| LEE | NDB | Leesburg | | 335.00 | 04W | 37.3 nm |
| GGL | NDB | Geiger Lake | | 375.00 | 05W | 37.5 nm |
| RHZ | NDB | Zephyrhills | | 253.00 | 03W | 38.3 nm |
| COI | NDB | Merritt Island | | 247.00 | 05W | 39.7 nm |
| SQT | NDB | Satellite | | 257.00 | 03W | 40.6 nm |
| PCM | NDB | Plant City | | 346.00 | 02W | 41.9 nm |
| DED | NDB | Deland/dcmsnd | | 201.00 | 05W | 47.5 nm |
| COF | TACAN | Patrick | 097X | | 04W | 43.8 nm |
| TTS | TACAN | Kennedy Space Center | 059Y | | 00E | 44.1 nm |
| MLB | VOR/DME | Melbourne | 037X | 110.00 | 02W | 43.9 nm |
| ORL | VORTAC | Orlando | 059X | 112.20 | 00E | 16.1 nm |
| LAL | VORTAC | Lakeland | 107X | 116.00 | 01E | 35.6 nm |
Remarks
- NOISE SENSITIVE AREA 1/2 MILE NORTH OF AER 24. NO EARLY TURNOUTS ON RY 6 DEPS.
- REQ ALL JETS/TURBO PROPS USE NBAA CLOSE-IN PROCEDURES.
- RY 15 IS PREFERRED CALM WIND RY.
- ISM CLSD TO ULTRALGT ACFT EXCEPT BY PRIOR PERMISSION FR AMGR.
- RY 6 HOLDING BAY RESTRICTED TO ACFT WITH WINGSPAN OF 49 FT OR LESS.
