| Airport ICAO Code: | LFBD |
| Airport IATA Code: | BOD |
| Longitude/Latitude: | W 000° 42' 56.00"/N 44° 49' 42.01" -0.715556/44.828335 |
| Elevation: | 162 ft / 49.38 m |
| Location: | Merignac Airport, France |
| Magnetic Variation: | W 1°24.2' (2008-04) |
| Time Zone: | UTC+1(+2DT) |
| Type | Name | Freq 1 | Freq 2 | Freq 3 | Freq 4 | Freq 5 |
|---|---|---|---|---|---|---|
| Approach Control | AQUITAINE APP | 118.6 M | 119.275 M | 126.725 M | 234.0 M | 338.275 M |
| Arrival Control | APP | 121.2 M | 362.3 M | |||
| Automatic Terminal Information Service | ATIS | 131.15 M | ||||
| Ground Control | GND | 121.9 M | 121.725 M | |||
| Information | AQUITAINE INFO | 120.575 M | ||||
| Operations | OPNS | 143.175 M | ||||
| Tower | TWR | 118.3 M | 231.5 M |
| Dimension: | 10171 x 148 ft / 3100.1 x 45.1 m |
| Surface: | Asphalt, asphaltic concrete, tar macadam, or bitumen bound macadam. |
| Runway 05 | Runway 23 | |
|---|---|---|
| Longitude: | -0.728983 / W 000° 43' 44.34" | -0.701000 / W 000° 42' 03.60" |
| Latitude: | 44.819103 / N 44° 49' 08.77" | 44.838694 / N 44° 50' 19.30" |
| End Elevation: | 160.0 ft | 151.0 ft |
| Alignment: | 046.0 | 226.0 |
| Slope: | -0.1 | 0.1 |
| Touchdown Zone Elev.: | 160.0 | 157.0 |
| Lighting System 1: | Centerline Lighting System | Touchdown Zone Lighting |
| Lighting System 2: | High Intensity Runway Lights | Centerline Lighting System |
| Lighting System 3: | Runway End Identifier Lights | High Intensity Runway Lights |
| Lighting System 4: | PAPI - Precision Approach Path Indicator | Runway End Identifier Lights |
| Lighting System 5: | ALSF-2 | |
| Lighting System 6: | PAPI - Precision Approach Path Indicator |
| Dimension: | 7923 x 148 ft / 2414.9 x 45.1 m |
| Surface: | Asphalt, asphaltic concrete, tar macadam, or bitumen bound macadam. |
| Runway 11 | Runway 29 | |
|---|---|---|
| Longitude: | -0.729242 / W 000° 43' 45.27" | -0.699897 / W 000° 41' 59.63" |
| Latitude: | 44.831567 / N 44° 49' 53.64" | 44.825411 / N 44° 49' 31.48" |
| End Elevation: | 153.0 ft | 160.0 ft |
| Alignment: | 107.0 | 287.0 |
| Slope: | 0.1 | -0.1 |
| Touchdown Zone Elev.: | 161.0 | 162.0 |
| Lighting System 1: | High Intensity Runway Lights | High Intensity Runway Lights |
| Lighting System 2: | Runway End Identifier Lights | Runway End Identifier Lights |
| Lighting System 3: | PAPI - Precision Approach Path Indicator | PAPI - Precision Approach Path Indicator |
| Fluid - LHOXRB |
| Fuel - Avbl 0500-2200Z++ (NC-100LL, A1, A1+) |
| Lighting - PAPI Rwy 05 GS 3.4 . |
| Noise Abadment - See AP/2 Supplementary Arpt Info. |
| Oil - O-156 |
| Restricted - Rwy 11/29 proh to Cat C and D four eng acft with outer eng span greater than 102'. Rwy 23 std cond for use is experimentally, max tailwind 6kt. Twy S2, S3 and W3 clsd. PPR 24 hr, before 1300Z++ hol and wkend. Show apvl Nr on line 18 of FPL |
| Restricted - . PPR fone C33.5.56.13.62.67. |
