Latest photos of Winnemucca Municipal Airport (WMC)
-
by S B J
-
by Daron Lynch
-
by Daron Lynch
Location & QuickFacts
FAA Information Effective: | 2013-12-12 |
Airport Identifier: | WMC |
Airport Status: | Operational |
Longitude/Latitude: | 117-48-21.2000W/40-53-47.8000N -117.805889/40.896611 (Estimated) |
Elevation: | 4308 ft / 1313.08 m (Surveyed) |
Land: | 968 acres |
From nearest city: | 5 nautical miles SW of Winnemucca, NV |
Location: | Humboldt County, NV |
Magnetic Variation: | 16E (1995) |
Owner & Manager
Ownership: | Publicly owned |
Owner: | City/county Of Winnemucca WINNEMUCCA CITY MGT CONTACT STEVE WEST. |
Address: | 90 West 4th Street Winnemucca, NV 89445 |
Phone number: | 775-623-6333 |
Manager: | Stephen West FBO - WINNEMUCCA AIR SERVICE 775-623-5091. |
Address: | 90 West Fourth Street Winnemucca, NV 89445 |
Phone number: | 775-623-6333 |
Airport Operations and Facilities
Airport Use: | Open to public |
Wind indicator: | Yes |
Segmented Circle: | Yes |
Control Tower: | No |
Lighting Schedule: | SEE RMK MIRL RY 14/32 PRESET LOW INTST; TO INCR INTST ACTVT - CTAF. |
Beacon Color: | Clear-Green (lighted land airport) |
Landing fee charge: | No |
Sectional chart: | Klamath Falls |
Region: | AWP - Western-Pacific |
Traffic Pattern Alt: | 800 ft |
Boundary ARTCC: | ZLC - Salt Lake City |
Tie-in FSS: | RNO - Reno |
FSS on Airport: | No |
FSS Toll Free: | 1-800-WX-BRIEF |
NOTAMs Facility: | WMC (NOTAM-d service avaliable) |
Federal Agreements: | NGY2 |
Airport Communications
CTAF: | 122.800 |
Unicom: | 122.800 |
Runway Information
Runway 02/20
Dimension: | 4800 x 75 ft / 1463.0 x 22.9 m |
Surface: | ASPH, Good Condition |
Weight Limit: | Single wheel: 28000 lbs. |
Edge Lights: | Medium |
|
Runway 02 |
Runway 20 |
Longitude: | 117-48-22.0899W | 117-47-42.2397W |
Latitude: | 40-53-27.5117N | 40-54-04.0370N |
Elevation: | 4303.00 ft | 4307.00 ft |
Alignment: | 40 | 127 |
Traffic Pattern: | Left | Left |
Markings: | Basic, Good Condition | Basic, Good Condition |
Obstruction: | , 50:1 slope to clear | 12 ft road, 500.0 ft from runway, 25:1 slope to clear |
Runway 14/32
Dimension: | 7000 x 100 ft / 2133.6 x 30.5 m |
Surface: | ASPH, Good Condition |
Weight Limit: | Single wheel: 75000 lbs. Dual wheel: 125000 lbs. Dual tandem wheel: 200000 lbs. |
Edge Lights: | Medium |
|
Runway 14 |
Runway 32 |
Longitude: | 117-48-50.2130W | 117-48-18.4324W |
Latitude: | 40-54-21.6136N | 40-53-16.8028N |
Elevation: | 4301.00 ft | 4303.00 ft |
Alignment: | 127 | 127 |
Traffic Pattern: | Left | Left |
Markings: | Non-precision instrument, Good Condition RY 14/32 MARKINGS FADED. | Non-precision instrument, Good Condition |
Crossing Height: | 40.00 ft | 0.00 ft |
VASI: | 2-box on left side | |
Visual Glide Angle: | 3.00° | 0.00° |
Obstruction: | 30 ft pline, 1000.0 ft from runway, 26:1 slope to clear | , 50:1 slope to clear |
Helipad H1
Dimension: | 25 x 25 ft / 7.6 x 7.6 m |
Surface: | CONC, |
|
Runway H1 |
Runway |
Traffic Pattern: | Left | Left |
Helipad H2
Dimension: | 25 x 25 ft / 7.6 x 7.6 m |
Surface: | CONC, |
|
Runway H2 |
Runway |
Traffic Pattern: | Left | Left |
Radio Navigation Aids
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
INA | VOR/DME | Winnemucca | 019X | 108.20 | 16E | 0.3 nm |
SDO | VORTAC | Sod House | 090X | 114.30 | 18E | 32.4 nm |
BAM | VORTAC | Battle Mountain | 059X | 112.20 | 18E | 44.8 nm |
