FAA Information Effective: | 2013-12-12 |
Airport Identifier: | 11A |
Airport Status: | Operational |
Longitude/Latitude: | 085-29-06.8000W/31-53-00.0000N -85.485222/31.883333 (Estimated) |
Elevation: | 435 ft / 132.59 m (Surveyed) |
Land: | 56 acres |
From nearest city: | 2 nautical miles W of Clayton, AL |
Location: | Barbour County, AL |
Magnetic Variation: | 00E (1980) |
Ownership: | Publicly owned |
Owner: | City Of Clayton |
Address: | Po Box 385 Clayton, AL 36016 |
Phone number: | 334-775-9176 |
Manager: | City Of Clayton |
Address: | Box 385 Clayton, AL 36016 |
Phone number: | 334-775-9176 |
Airport Use: | Open to public |
Wind indicator: | Yes |
Segmented Circle: | Yes |
Control Tower: | No |
Lighting Schedule: | SEE RMK ACTVT HIRL RY 9/27 AND PAPI RY 9 AND 27 - CTAF. |
Beacon Color: | Clear-Green (lighted land airport) |
Landing fee charge: | No |
Sectional chart: | New Orleans |
Region: | ASO - Southern |
Boundary ARTCC: | ZTL - Atlanta |
Responsible ARTCC: | ZJX - Jacksonville |
Tie-in FSS: | ANB - Anniston |
FSS on Airport: | No |
FSS Toll Free: | 1-800-WX-BRIEF |
NOTAMs Facility: | ANB (NOTAM-d service avaliable) |
Federal Agreements: | N |
CTAF: | 122.900 |
Bottled Oxygen: | NONE |
Bulk Oxygen: | NONE |
Dimension: | 5010 x 80 ft / 1527.0 x 24.4 m |
Surface: | ASPH, Good Condition |
Edge Lights: | High |
Runway 09 | Runway 27 | |
---|---|---|
Longitude: | 085-29-35.6706W | 085-28-37.9679W |
Latitude: | 31-53-02.8445N | 31-52-57.0761N |
Elevation: | 422.00 ft | 434.00 ft |
Alignment: | 97 | 127 |
Traffic Pattern: | Left | Left |
Markings: | Non-precision instrument, Good Condition | Non-precision instrument, Good Condition |
Crossing Height: | 30.00 ft | 37.00 ft |
Displaced threshold: | 279.00 ft | 0.00 ft |
VASI: | 2-light PAPI on left side | 2-light PAPI on left side |
Visual Glide Angle: | 3.20° | 3.75° |
Obstruction: | 24 ft brush, 654.0 ft from runway, 20 ft right of centerline, 18:1 slope to clear APCH RATIO 38:1 FM DSPLCD THLD. | 49 ft trees, 1263.0 ft from runway, 103 ft left of centerline, 21:1 slope to clear |
VFR ONLY |
